Off Topic e9 Empresas y tribulaciones en BBlau042

[dequincey]

Y me dio tiempo a otra cosilla, de la caja,

el piñón para el odometro mecanico, lleva un retén que suele fugar


Sacar esta pieza se las trae






Para extraer el retén viejo












Esto va aquí…



[dequincey]

come to the dashboard wood, as I have two of these, doing in pairs, on one of them I found a crack in the weakest point, it is a delicate part, not only narrow but also thin due to a cavity below, it is prone to cracks, both of mine were broken, this one was catastrophic , so did a compound to restore the structural rigidity by adding four strong pieces stitching the wood



[dequincey]

Doing the other one, placing the vinyl and cutting the boundaries,



[dequincey]

Speedo,faulty, usual culprit, delicate thing, doable…



[dequincey]

Alotra,


Soportes de placa de palanca de cambios



[saicaman]

¿Silemblocks "home made"?



[dequincey]

El ohne luftung…

dos diferentes de blau, y hay una tercera, más reciente



[dequincey]

siguiendo con salpicadero,…presentando cosas


Mas o menos asi…me lo ha chivado xevi



principio y marcas



Recuperando grab-bar



[saicaman]

¿Qué madera es?



[dequincey]

¿Qué madera es?

madera de npi, ni idea, entre cerezo y nogal estoy



[dequincey]

who needs metaverse ? Cuando puedes coser…

the rebel paper template...and the solid keepers

ready

fantastic

some tips,


before starting use only one side marked and place the other side with plenty of excess, you will cut it afterwards


sew 4mm inside the border or give 4 mm excess, when you turn it inside out you will have that small corner to introduce it in the rubber channel of the lateral console


before starting sewing just sew 1cm long in both extremes to somehow fix the 2 pieces so that they do not move in excess


enjoy



[xavier sarda]

siguiendo con salpicadero,…presentando cosas


Mas o menos asi…me lo ha chivado xevi



principio y marcas



Recuperando grab-bar

A sus pies maestro!



[dequincey]

Otra tribulación, esta vez resulta a medias,

para la caja renovada ando sin pivote

es esta cosita…

i can see no other way than pressure, but would it be a thread there



[dequincey]

Esto lo



[dequincey]

>

A ver si hago una

went to a friend to reproduce one as they are NLA



[xavier sarda]

>

A ver si hago una

went to a friend to reproduce one as they are NLA

Un tornero te tendria que poder hacer una copia….



[dequincey]

mas madera, calefaccion...

while we are on this...

swapping the old with the NOS



[dequincey]

Un tornero te tendria que poder hacer una copia….

asi es...
...y me la ha hecho



[dequincey]



[dequincey]

finally it was necessary to build one

diameters 12 and 23, a bit tricky, some 0,... needed to be removed to instert in their respective places



[dequincey]

a difficult time it came with the need for fixing the horizontal wood piece to the vertical ones

i made a trial on the body mounted on duct tape, it seemed fine, but setting some screws freeze everything in place forever,

i used the trim part as a support to join both wood bits on top,
them i checked how the shapes fit together,

made some changes in positions and started with the joint procedure

i felt that in order to introduce the screws the process is a bit laborious as drilling is involved

i found better to use nails as references, but i predrill the position, the nails to be removed afterwards

i used torx headed SS screws,

3x30 for the wood to wood, drilling with a 2mm drill

















then 3x16 for the top alu trim, a bit longer than the originals, but originals seemed ridiculous like 3x8

went well, satisfied with outcome.



[dequincey]

paneles de consolas laterales:


as to the wood that was finished months ago it still needed the rubber and the foam, so...

so, once all this was ready it only took 2 hours to complete the upholstery process,...i am getting old...

most difficult part is to get the edges inside the rubber channel...

start in one corner back side

then turn other side and pull while puting staples to fix

keep the tension and work the other end

tools



relevant:

ready for the alu trim lines



[dequincey]

y comprobando el conducto de la calefaccion: los fieltros se usan para sellar las bocas, y en el interior para reducir el ruido producido por el aire y amortiguar el ruido del exterior



[dequincey]

rear lights,



[LM Informat]

los hay con paciencia...



[dequincey]

paneles de consolas laterales:


as to the wood that was finished months ago it still needed the rubber and the foam, so...

so, once all this was ready it only took 2 hours to complete the upholstery process,...i am getting old...

most difficult part is to get the edges inside the rubber channel...

start in one corner back side

then turn other side and pull while puting staples to fix

keep the tension and work the other end

tools



relevant:

ready for the alu trim lines

Para terminar con las consolas el todo o nada de las molduras de aluminio,

si te equivocas hay que tirar las fundas y hacerlas nuevas, es un momento crítico



[dequincey]

BTW, I have done a second pair that will be available for sale shortly



[saicaman]

"extasiaaaaaoooo" me tienes siempre



[dequincey]

"extasiaaaaaoooo" me tienes siempre

my life es un estado de extasiamiento constante…



[dequincey]

en esta seccion trataremos de los faros delanteros

los divinos pequeños detalles,...
